Meridian 218 Zone Controller

AUDIO INPUTS

One 2-channel digital coaxial S/PDIF input. 44.1kHz to 192kHz sampling and up to 24-bit
One 2-channel Meridian Speakerlink input. 44.1kHz to 192kHz sampling and up to 24-bit
One 2-channel digital optical TOSLINK input. 44.1kHz to 96kHz sampling and up to 24-bit
One 2-channel analogue input
One network input (Ethernet) for connection to Meridian
Sooloos or alternative control interface

AUDIO OUTPUTS

2 Speakerlink digital outputs
Single RCA digital output
2-Channel unbalanced analogue output (192kHz DAC)

CONTROL SIGNALS

IP Control: Network socket for use with Meridian IP Control iPad App, other Sooloos control interface, and third-party control systems
IP Control: IR on 3.5mm jack

DISPLAY

LEDs to indicate source selection and MQA status

DIMENSIONS

HEIGHT: 42mm [1.65in]
WIDTH: 204mm [8.03in]
DEPTH: 150mm [5.91in]
WEIGHT: Standalone: 0.56Kg [1.2lbs]

CONSTRUCTION

1U tall rack kit available with space for two units
Universal mounting bracket
All-aluminium chassis

POWER

High performance power supply: 100V ac 50/60 Hz | 110-120V ac 50/60Hz | 220-240V ac 50/60Hz
